Key Features

• Handles a pallet up to 21.75” x 22”

• Lifts and Lowers up to 2,500 pounds

• Lifts to meet cutter table heights up to 36-1/2”

• Hydraulic Lifting Power · Welded Steel Frame Construction

• Auto or Manual Up/Down Controls

• Adjustable Height Infrared Auto Lift/Lower Sensor

• Sensor Arm is Mountable on Left or Right of Stack

• Swivel Mounted Control Arm

• One-Year Warranty – top to bottom

Specifications

• Maximum Pile Dimensions 21.75” x 22” / 55.2 x 55.9 cm

• Maximum Weight on Shelf (Load Capacity) 2,500 lbs / 933 kg

• Maximum Lift Height 40" / 102 cm

DIMENSIONS

• Overall Height 65.4" / 166 cm

• Overall Width 35” / 88.9 cm

• Overall Depth 42” / 106.7 cm

• Net Weight (approximate) 1,500 lbs / 680 kg

• Shipping Weight (approximate) 1,670 lbs / 658 kg

ELECTRICAL

• Standard 1/2 HP, Single Phase, 120 Volt, 60 Hz, AC, 12 Amps (service size 15 Amps)
